600 × 1200 mm travertine slab

Inspect the source, maps and package of a travertine study with explicit design dimensions. The dimensions in this example are design inputs. Image-derived maps are not measured scans. Inspect the source and settings below, then open the same recipe in the editor.

Open this example in the editorDownload recipe (JSON)Download sample package (ZIP)
Actual recipe settings
UnitHorizontal / vertical jointBondRows × columnsResolution
600 × 1200 mm0 / 0 mmstack bond1 × 11024 px
Source surface used in this example
Source surface — MATERIALHAUS design study. No manufacturer-performance or calibrated-scan claim. Download source

Workflow steps

  1. Open the example in the editor. Source and recipe load together.
  2. Compare dimensions and joints with the table above.
  3. Enable repeat and dimension views and inspect the boundaries.
  4. Change one setting and review the result before saving.
  5. Generate files with your available access and check them in the target software.

Five-point checklist

  1. Record the source and permission to use the image.
  2. Set unit dimensions and joint width separately.
  3. Inspect repeat boundaries and the larger surface.
  4. Check that textures and drawing files share the same dimensions.
  5. Test the files in the destination software and keep version notes.

Verification scope: example loading and web preview. No Revit, Blender or SketchUp validation record is provided yet.
