600 × 600 mm tile, 4 mm joint
Check a 604 mm repeat pitch and four periods spanning 2416 mm with a square stone tile layout. The dimensions in this example are design inputs. Image-derived maps are not measured scans. Inspect the source and settings below, then open the same recipe in the editor.
| Unit | Horizontal / vertical joint | Bond | Rows × columns | Resolution |
|---|---|---|---|---|
| 600 × 600 mm | 4 / 4 mm | stack bond | 4 × 4 | 1024 px |
Workflow steps
- Open the example in the editor. Source and recipe load together.
- Compare dimensions and joints with the table above.
- Enable repeat and dimension views and inspect the boundaries.
- Change one setting and review the result before saving.
- Generate files with your available access and check them in the target software.
Calculation: 600 + 4 = 604 mm. Four periods: 4 × 604 = 2416 mm. Four finite tiles and three internal joints: 4 × 600 + 3 × 4 = 2412 mm.
Five-point checklist
- Record the source and permission to use the image.
- Set unit dimensions and joint width separately.
- Inspect repeat boundaries and the larger surface.
- Check that textures and drawing files share the same dimensions.
- Test the files in the destination software and keep version notes.
Verification scope: example loading and web preview. No Revit, Blender or SketchUp validation record is provided yet.
